Tiêu thụ năng lượng thấp, có thể điều chỉnh tốc độ gió hoạt động, chi phí vận hành cực thấp.
Thiết kế hệ thống đường ống gió đặc biệt và hệ thống gió đồng đều, tiếng ồn thấp, tốc độ gió đồng đều.
Nhẹ, lắp đặt bằng cách gắn từ trần, dễ dàng lắp đặt và bảo trì hơn.
Có thể thực hiện điều khiển từ xa bằng máy tính để điều chỉnh áp suất, tần số và tốc độ.
Bảng thông số kĩ thuật:
|
Model |
FFU-6060 | FFU-6060 | FFU-6060 | FFU-6060 | |
| Kích thước | 608x608x320 | 578x578x320 | 608x1218x320 |
578x1178x320 |
|
|
Cabinet material |
Cold Rolled Sheet, Zinc Aluminum Plated Steel Sheet, Aluminum Sheet, SUS304/430 Stainless Steel Sheet Scratched or Mirror |
||||
|
Main Filter Bộ lọc chính |
Size |
600x600x69 | 570x570x69 | 600x1210x69 | 570x1170x69 |
|
Filter material |
Ultra-fine fiberglass | Ultra-fine fiberglass | Ultra-fine fiberglass | Ultra-fine fiberglass | |
| Air | 650m³/h | 550m³/h | 1300m3/h |
1200m³/h |
|
|
Surface wind speed |
0.35-06m/s | 0.35-06m/s | 0.35-06m/ | 0.35-06m/s | |
| Filtration efficiency | 99.99%0.3μm | 99.99%0.3 μn | 99.99%0.3μm |
99.99%0.3μm |
|
| Initial pressure loss | 125Pa | 125Pa | 125Pa |
125Pa |
|
|
Pre-Filter Bộ lọc phụ |
Size |
390x390x21 | 490x490x21 | 490x490x2 |
490x490x21 |
|
Filtering level |
G3 |
G3 | G3 | G3 | |
| Initial pressure loss | 40Pa | 40Pa | AGP |
40Pa |
|
|
Fan model |
Germany EBM | Germany EBN | Germany EBN | Germany EBM | |
| Power supply | 220V/50Hz | 220V/50Hz | 220V/50Hz |
220V/50Hz |
|
|
Static pressure outside the machine |
50-100Pa | ||||
| Output power |
140/150W |
||||
|
Adjust the controls |
Stepless adjustment switch, plus power supply guidance and fuse current protection device | ||||
| Noise level |
<60 decibel |
||||
|
Alternative |
The main filter is a ULPA ultra-high efficiency filter | ||||
|
The appearance material can be determined according to specific requirements or working environment |
|||||
|
EC control system and control software |
|||||
|
Air intake takes over the equipment |
|||||
|
Primary filter filtration level |
|||||
Application: Cleanrooms with cleanliness levels of Class 10-10000, clean benches, clean booths, clean production lines, and other purification and process equipment with strict cleanliness requirements.
Product Features
High-quality, high-performance, low-noise external rotor backward curved centrifugal fan
Built-in air duct diversion system, reducing noise and pressure loss, improving fan efficiency
FFU can use multiple methods to control speed
Can be used with non-baffle high-efficiency filters (HEPA/ULPA)
Energy-saving and environmentally friendly, low fan power consumption, effectively reducing costs
Product Advantages
Simple and generous cabinet appearance design
Optimized internal air duct diversion design
Complete large-scale group control operating system
Product with EU CE certification and UL fire safety certification
Can be equipped with a high-efficiency liquid tank design
Can be equipped with a dust emission test design
Core Advantages of FFU
1. Modular Design
Can be installed individually or in combination, flexibly adapting to different space needs, facilitating expansion or layout adjustment.
2. High Efficiency and Energy Saving
Using EC (electronically commutated) fans, low power consumption and adjustable speed, saving 30%-50% energy compared to traditional central air conditioning systems.
3. Precise Cleanliness Control
HEPA/ULPA filters have a filtration efficiency ≥99.99% for 0.3μm particles (HEPA H13 and above).
4. Low Noise Operation
High-quality fan and shock absorption design, noise can be controlled below 50dB (at 1.5m).
5. Easy Maintenance
Filters can be replaced individually without shutting down the entire system for maintenance, reducing maintenance costs.
6. Space Saving
Direct ceiling installation, no complex ductwork required, especially suitable for places with limited ceiling height.
Shenzhen Chuang Hong Yu Purification Equipment Co., Ltd. - Creating ultra-clean spaces, leading the future of cleanliness!
FFU, Fan Filter Unit, Fan Filter Unit, Clean Bench, Clean Booth
Product Applications
Cleanrooms with cleanliness levels of Class 10-10000
Clean benches, clean booths, clean production lines, and other purification and process equipment with strict cleanliness requirements.
Product Specifications and Parameters
|
Series |
F-2×2 |
F-2×3 |
F-2×4 |
F-3×4 |
F-4×4 |
|
W×L×H(mm) |
575×575×250 |
575×875×250 |
575×1175×250 |
875×1175×275 |
1175×1175×275 |
|
Air Speed (m/h) |
0.45 |
0.45 |
0.45 |
0.45 |
0.45 |
|
Air Volume (m3/h) |
550 |
900 |
1200 |
1650 |
2200 |
|
Total Static Pressure (Pa) |
250 |
220 |
210 |
250 |
205 |
|
Power (w) |
80 |
110 |
120 |
175 |
245 |
|
Noise (dB) |
50 |
51 |
52 |
54 |
56 |
|
Vibration (mm/s) |
0.7 |
0.8 |
1.2 |
1.2 |
1.2 |
|
Power Supply |
220-240V 50HZ |
||||
